8200P 8 PORT MANIFOLD 1" BRASS
Details
Manifold
Width 21-3/8 Inch
Height 16-1/2 Inch
Number of Ports 8
End Connection 1 Inch Threaded
Seal Material EPDM
Temperature Rating 230 Deg F
Pressure Rating 125 PSI
Applicable Standard ISO 9002
Flow Rating 2 to 16 GPM
Includes Integrated Adapter, 1 Inch Brass Bar, (2 to 20) High-Temperature Polymer Flow Meter, (1) Brass B124 UNS C37700 Supply Header, (2) Brass B124 UNS C37700 Manifold End Plug, (1) Chrome Plated Steel Hex Key, (2 to 12) High-Temperature Polymer Circuit Valve, (2) Galvanized Steel Mounting Bracket, (1) Brass B124 UNS C37700 Return Header, (2) Brass B124 UNS C37700 Isolation Valve, (2) Aluminum Case/Glass Face Thermometer, (2) Brass B124 UNS C37700 Tailpiece/Air Vent/Fill and Purge Valve/Cap
