SP10552KH ELEMENT CO 240V/3500W WATER HEATER PART
Details
Electric Water Heater Element
Item Element
Type Straight
Size 0.26 Inch Diameter x 12.38 Inch Length
Material Copper (Outer Sheath)
Used On Item Water Heater
Voltage Rating 208/240 Volt
Power Rating 2630 Watt at 208 Volt/3500 Watt at 240 Volt
Mounting Type Threaded
Nominal Thread Size 1 Inch x 11-1/2 Inch NPSM
Hex Head Size 1-1/2 Inch
Cold Resistance 16.5 Ohm
Outside Diameter 1-9/32 Inch
Watt Density 133 Watt per Square Inch at 208 Volt, 177 Watt per Square Inch at 240 Volt
Includes Gasket
Item Element
Type Straight
Size 0.26 Inch Diameter x 12.38 Inch Length
Material Copper (Outer Sheath)
Used On Item Water Heater
Voltage Rating 208/240 Volt
Power Rating 2630 Watt at 208 Volt/3500 Watt at 240 Volt
Mounting Type Threaded
Nominal Thread Size 1 Inch x 11-1/2 Inch NPSM
Hex Head Size 1-1/2 Inch
Cold Resistance 16.5 Ohm
Outside Diameter 1-9/32 Inch
Watt Density 133 Watt per Square Inch at 208 Volt, 177 Watt per Square Inch at 240 Volt
Includes Gasket
