1/2 2 PC LARGE PORT GAS VALVE
Details
Gas Ball Valve
Actuation Type T-Handle
Nominal Size 1/2 Inch x 1/2 Inch
End Connection Female Threaded x Female Threaded
End to End Distance 2.17 Inch
Ball Material ASTM B124 UNS C37700 Chrome Plated Brass
Body Material ASTM B124 UNS C37700 Brass
Stem Material ASTM B124 UNS C37700 Brass
Seat Material TPFE
Handle Material ASTM B86 Coated Zinc Aluminum
Pressure Rating 400 PSI CWP
Application Low/Moderate Pressure Gas
Applicable Standard ANSI Z21.15, ANSI/ASME B1.20.1, ISO 9002, CSA (Canada and US), UL
Overall Dimension 2.17 Inch Length x 1.14 Width
Outer Diameter 0.39 Inch
Material AISI 1010 Zinc Plated Steel (Handle Screw), ASTM B16 UNS C36000 Forged Brass (Packing Nut/End Adapter)
